ltems
|
Specifications
|
|
Combination method
|
12S1P
|
|
Nominal capacity
|
25000mAh @ 0.2C Discharge
|
|
Minimum capacity
|
23750mAh @ 0.2C Discharge
|
|
Nominal voltage
|
45.6V
|
|
Standard charging current
|
0.5C CC(constant current) charged to 52.2V, then CV(constant voltage 52.2V) charge till charge current decline to ≤ 0.02C
|
|
Rapid charge
|
Constant curren to1.0C，constant voltage 52.2V，cut-off current 0.02C
|
|
Charging time
|
Standard charging: 3.0hours(Ref.)
Rapid charge: 1.5hours(Ref.)
|
|
Constant discharge current
|
Constant current 7.5C end voltage 36.0V
|
|
Peak discharge current
|
Peak current 15C end voltage 36.0V
|
|
High rate discharge
|
≥7.2min
Standard Charge/rest 5.0min discharge at 7.5C to 36.0V |
|
Operating temperature
|
Charging: 0℃-40℃
Discharging: -20℃-60℃ |
|
Storage temperature
|
-10℃~ +45℃（with charge 40-50%）
|
|
Combination standard
|
Capacity difference≤250mAh
Resistance difference ≤0.3mΩ Voltage difference ≤20mV |
|
PACK voltage (Shipping status)
|
45~46.32V（cell 3.75~3.86V）
|
|
Internal Impedance
|
≤15.0mΩ
|
|
Max dimensions
|
124.5*94*206mm（T*W*H）
|
|
Pack weight
|
4940±250g
|
