ltems
|
Specifications
|
|
Combination Method
|
6S1P
|
|
Nominal Capacity
|
12000mAh @ 0.2C Discharge
|
|
Minimum Capacity
|
11600mAh @ 0.2C Discharge
|
|
Nominal Voltage
|
22.8V
|
|
Voltage Difference
|
≤30mV
|
|
Standard Charging Current
|
0.5C CC(constant current) charged to 25.2V, then CV(constant voltage 25.2V) charge till charge current decline to ≤ 0.05C at 25℃
|
|
Max.Charging Current
|
2C CC(constant current) charged to 25.2V, then CV(constant voltage 25.2V) charge till charge current decline to ≤0.05C at 25℃
|
|
Full Voltage
|
25.2 +0.15 -0.06 V
|
|
Standard Discharge Current
|
0.5C(2.4A)
|
|
Max Continuous Discharge Current
|
Max Constant Current: 120A end voltage: 19.2V
|
|
Peak Discharge Curent
|
180A ≤3S
|
|
Cutoff Voltage
|
19.2V
|
|
PACK Voltage(As of shipment)
|
22.5-23.6V(cell 3.75-3.90V)
|
|
Internal Impedance
|
≤ 9.5mΩ
|
|
Max Dimensions (Including cables)
|
H: ≤280mm
W: ≤75mm
L: ≤45mm
|
|
Pack Weight
|
1250g
|
|
Operating Temperature
|
Charging: 0-60℃
Discharge: -20-60℃
|
