GENERAL
|
|
|
Dimension:
|
110x110x65mm
|
|
Weight:
|
730g
|
|
CHARGER
|
|
|
Input voltage:
|
DC 10~34V
|
|
Output voltage:
|
DC 1~34V
|
|
Max. input current:
|
60A
|
|
Charging current:
|
0.2~30A x2
|
|
Discharging current:
|
0.2~3.0A x2
|
|
Balance current:
|
1.5A/Cell Max
|
|
Max. discharging power:
|
30W x2
|
|
Max. charging power:
|
Single channel Max. 1000W; Whole model Max. 1500W
|
|
Abnormal voltage alarm:
|
support
|
|
Incorrect cell count setting alarm:
|
support
|
|
Supported battery types and cell count:
|
LiFe, Lilon, LiPo 1~8S, LiHv 1-7S, Pb 1-12S, NiMH, Cd 1-16S
|
|
Output interface:
|
XT60i（XT60 compatible）
|
|
Input interface:
|
XT90i（XT90 compatible）
|
|
Display:
|
3.5’’ 320×480 IPS LCD
|
|
Working temperature:
|
0~40℃
|
|
Storage temperature:
|
-20℃~60℃
|
